Zebra ZQ630 DT Printer
$2,748.00
The Zebra ZQ630 DT is a premium mobile direct thermal printer designed for on-the-go label and receipt printing, built for demanding warehouse, logistics and field environments. With a 4-inch print width, high capacity battery and rugged design, it keeps your operations moving even in tough conditions.
Technical Specifications
Print Technology
-
Direct Thermal (DT) – no ribbon required
Print Resolution
-
203 dpi (8 dots/mm)
Maximum Print Width:
-
Approximately 4.1 in (104 mm)
Maximum Print Speed:
- Up to ~4.5 in/second
(115 mm/s)
Memory & Processing:
-
256 MB RAM (standard)
-
512 MB Flash memory (standard)
Battery & Power:
-
6600 mAh (nominal) PowerPrecision+ Li-Ion removable battery
-
Built-in battery charger
Media Handling:
-
Media Types: Die-cut labels, tags, linerless labels, receipt paper
-
Minimum Label Length: ~0.5 in (12.7 mm)
-
Maximum Label Length: up to ~32 in (813 mm) or continuous
-
Media Width Range: ~2.0 in (51 mm) to ~4.4 in (112 mm) (linered)
-
Maximum Media Roll Diameter: ~2.6 in (66 mm) O.D. on core options
Connectivity / Wireless:
-
Wireless: Wi-Fi (802.11ac / optional newer) and Bluetooth (Classic/BLE)
-
USB and other interface options supported
Durability / Ruggedness:
-
Designed for mobile use: drop tolerance approx 6 ft (1.8 m) to concrete
-
Dust and water resistance rating: IP54 (with soft case) or IP43 standard
-
Center-loading media path for quick reloads
Environmental / Operating Conditions:
-
Operating Temperature: approx −4 °F to 122 °F (−20 °C to +50 °C)
-
Storage/Transportation Temperature: approx −13 °F to 149 °F (−25 °C to +65 °C)
-
Operating Humidity: 10% to 90% non-condensing
Physical Dimensions & Weight:
-
Approximate Dimensions: 7.35 in (L) × 6.5 in (W) × 3.25 in (H)
-
Weight with battery: approx 2.45 lbs (1.1 kg)
Software & Features:
-
Printer OS: Link-OS®
-
Supported Printer Languages: ZPL®, EPL™, CPCL™
-
Instant wake-up on Wi-Fi or Bluetooth
-
Large color display (on “Plus”/premium variants)
-
Backward accessory compatibility with QLn® series mobile printers
